Figure 81. Installing the intrusion switch
4. Connect the intrusion switch cable to the intrusion switch connector on the system board. See “System
board components” on page 19.
Power supply assembly
Your server supports one of the following power supply configurations:
• 250-watt non-hot-swap power supply (80 PLUS Bronze)
• 400-watt non-hot-swap power supply (80 PLUS Platinum)
Note: To support a discrete graphic adapter, you must select the 400-watt non-hot-swap power supply.
• “Removing the power supply assembly” on page 86
• “Installing the power supply assembly” on page 86
Although there are no moving parts in your server after the power cord has been disconnected, the following
warnings are required for your safety and proper Underwriters Laboratories (UL) certification.
DANGER
Hazardous moving parts. Keep fingers and other body parts away.
CAUTION:
Never remove the cover on a power supply or any part that has the following label attached.
Chapter 5. Replacing hardware 85
