14
Section 3 – Installing NVMe Devices in
P3 Tiny
There are only two Gen 4 M.2 slots in the P3 Tiny. No other drives can be
added to the system. The steps to access to these M.2 slots is explained in
this section. P3 Tiny supports up to a single-sided 2TB M.2 2280 drive in each
of the onboard slots.
Accessing the M.2 drives:
1. Disconnect the power and all connected devices.
2. Remove the rear screw, (1) in the image.
3. Slide the cover forward and lift to remove it (2).
4. Turn the system over and slide the bottom plate towards the front of the
system.
