7X06A00VLA 1x 6140 18C
140W 2.3GHz
1x 16GB
(2Rx8)
1x RAID
930-8i
8 / 16‡
SFF
Open
bay
Open
slot
5x PCIe x8 1x 1100W S Y Y N R4
7X06A01CLA 1x 6148 20C
150W 2.4GHz
1x 16GB
(2Rx8)
1x RAID
930-8i
8 / 16‡
SFF
Open
bay
Open
slot
5x PCIe x8 1x 1100W S Y Y N R4
7X06A026LA 1x 6148 20C
150W 2.4GHz
1x 16GB
(2Rx8)
1x RAID
930-8i
8 / 16‡
SFF
Open
bay
Open
slot
5x PCIe x8 1x 1100W S Y Y N R4
7X06A01WLA 1x 8160 24C
150W 2.1GHz
1x 16GB
(2Rx8)
1x RAID
930-8i
8 / 16‡
SFF
Open
bay
Open
slot
5x PCIe x8 1x 1100W S Y Y N R4
7X06A016LA 1x 8160 24C
150W 2.1GHz
1x 16GB
(2Rx8)
1x RAID
930-8i
8 / 16‡
SFF
Open
bay
Open
slot
5x PCIe x8 1x 1100W S Y Y N R4
TopSeller models - Latin America (Brazil only)
7X06100QBR 2x 4110 8C
85W 2.1GHz
4x 32GB
(2Rx4)
1x RAID
930-8i
8 / 10
LFF
Open
bay
4x 1Gb
RJ-45
2x PCIe x8 2x 750W
Platinum
E N Y N C2
7X06100NBR 1x 4114 10C
85W 2.2GHz
1x 32GB
(2Rx4)
1x RAID
930-8i
8 / 16‡
SFF
Open
bay
4x 1Gb
RJ-45
5x PCIe x8 2x 550W E N N N C2
7X06100PBR 2x 5118 12C
105W 2.3GHz
2x 32GB
(2Rx4)
1x RAID
930-8i
8 / 16‡
SFF
Open
bay
4x 1Gb
RJ-45
5x PCIe x8 2x 750W
Platinum
E N N N C2
TopSeller models - Latin America (Chile only)
7X06100JLA 1x 4110 8C
85W 2.1GHz
1x 16GB
(1Rx4)
1x RAID
930-16i 4GB
12 / 14
LFF
Open
bay
4x 1Gb
RJ-45
3x PCIe x8
1x PCIe x16
2x 750W
Platinum
S Y Y Y R2
7X06100GLA 1x 4110 8C
85W 2.1GHz
1x 16GB
(1Rx4)
1x RAID
930-16i 4GB
16 / 16‡
SFF
Open
bay
4x 1Gb
RJ-45
3x PCIe x8
1x PCIe x16
2x 750W
Platinum
E Y Y N R2
7X06100HLA 1x 4114 10C
85W 2.2GHz
1x 16GB
(1Rx4)
1x RAID
930-16i 4GB
16 / 16‡
SFF
Open
bay
4x 1Gb
RJ-45
3x PCIe x8
1x PCIe x16
2x 750W
Platinum
E Y Y N R2
TopSeller models - Latin America (Colombia only)
7X06100LLA 1x 4116 12C
85W 2.1GHz
1x 16GB
(1Rx4)
1x RAID
930-16i 4GB
16 / 16‡
SFF
Open
bay
4x 1Gb
RJ-45
3x PCIe x8
1x PCIe x16
1x 550W S Y Y N R2
7X06100MLA 2x 5120 14C
105W 2.2GHz
2x 16GB
(1Rx4)
1x RAID
930-16i 4GB
16 / 16‡
SFF
Open
bay
4x 1Gb
RJ-45
2x 10Gb
RJ-45**
3x PCIe x8
1x PCIe x16
2x 1100W S Y Y N R2
TopSeller models - Latin America (except Chile)
7X06100KLA 1x 5118 12C
105W 2.3GHz
1x 16GB
(1Rx4)
1x RAID
930-16i 4GB
16 / 24‡
SFF
Open
bay
4x 1Gb
RJ-45
3x PCIe x8
1x PCIe x16
2x 750W
Platinum
S Y Y Y R2
Model
number
Intel Xeon
processor*
(2 max)
Memory
RDIMM
(24 max)
Storage
controller
Drive
bays
(std /
max) Drives
Eth.
LOM
I/O slots
(7 max)^
Power
supply
(2 max)
* Processor details: Processor quantity and model, cores, thermal design power (TDP), and core speed.
^ The server supports two onboard PCIe slots 4 and 7 and up to five I/O slots on the riser cards. An internal storage controller occupies
the PCIe slot 7.
† 4x 1 GbE RJ-45 ports on the ThinkSystem Broadcom NetXtreme PCIe 1Gb 4-Port RJ45 Ethernet Adapter installed in the server.
‡ Models with 8, 16, or 24 SFF drive bays can be upgraded with 2x additional LFF rear drive bays (See Internal storage for details) that
are not included in the maximum quantity shown.
** 2x 10 GbE ports on the Intel X550-T2 adapter.
