Storage
controller
12 Gbps SAS/6 Gbps SATA RAID:
RAID 0/1/10/5/50 with RAID 530-8i or RAID 730-8i 1GB Cache.
RAID 0/1/10/5/50/6/60 with RAID 930-8i 2GB Flash, or 16i 4 GB or 8 GB Flash, or 24i 4 GB Flash.
12 Gbps SAS/6 Gbps SATA non-RAID: 430-8i or 16i HBA.
NVMe PCIe non-RAID: Onboard NVMe, 1610-4P NVMe Switch Adapter.
Optical drive
bays
None. Support for an external USB DVD RW Optical Disk Drive (See Optical drives).
Network
interfaces
Onboard LOM slot for up to 4x 1/10 Gb Ethernet ports:
2x or 4x 1 GbE RJ-45 ports (no 10/100 Mb support)
2x or 4x 10 GbE RJ-45 ports (no 10/100 Mb support)
2x or 4x 10 GbE SFP+ ports (no 10/100 Mb support)
Optional Mezzanine LOM (ML2) slot for dual-port 10 GbE cards with SFP+ or RJ-45 connectors
or single- or dual-port 25 GbE cards with SFP28 connectors.
1x RJ-45 10/100/1000 Mb Ethernet systems management port.
I/O expansion
slots
Up to seven slots. Slots 4 and 7 are the fixed slots on the system planar, and the remaining slots depend
on the riser cards installed. The slots are as follows:
Slot 1: PCIe 3.0 x16 or PCIe 3.0 x8; full-height, half-length (PCIe x16 slot is double-wide)
Slot 2: PCIe 3.0 x8; full-height, half-length (not present if the slot 1 is PCIe x16)
Slot 3: PCIe 3.0 x8 or ML2; full-height, half-length
Slot 4: PCIe 3.0 x8; low profile (vertical slot on system planar)
Slot 5: PCIe 3.0 x16; full-height, half-length
Slot 6: PCIe 3.0 x16; full-height, half-length
Slot 7: PCIe 3.0 x8 (dedicated to an internal RAID controller)
Slots 5 and 6 require the second processor to be installed.
Ports Front:
1x USB 2.0 port with XClarity Controller access.
1x USB 3.0 port.
1x DB-15 VGA port (optional).
Rear: 2x USB 3.0 ports and 1x DB-15 VGA port. Optional 1x DB-9 serial port.
Cooling Five (one processor) or six (two processors) hot-swap system fans with N+1 redundancy.
Power supply Up to two redundant hot-swap 550 W, 750 W, or 1100 W (100 - 240 V), or 1600 W (200 - 240 V) High
Efficiency Platinum AC power supplies, or 750 W (200 - 240 V) High Efficiency Titanium AC power
supplies. HVDC support (China only).
Video Matrox G200 with 16 MB memory integrated into the XClarity Controller. Maximum resolution is
1920x1200 at 60 Hz with 16 bits per pixel.
Hot-swap parts Drives, power supplies, and fans.
Systems
management
XClarity Controller (XCC) Standard, Advanced, or Enterprise (Pilot 4 chip), proactive platform alerts, light
path diagnostics, XClarity Provisioning Manager, XClarity Essentials, XClarity Administrator, XClarity
Integrators for VMware vCenter and Microsoft System Center, XClarity Energy Manager, Capacity
Planner.
Security
features
Power-on password, administrator's password, secure firmware updates, Trusted Platform Module
(TPM) 1.2 or 2.0 (configurable UEFI setting). Optional lockable front bezel. Optional Trusted
Cryptographic Module (TCM) or Nationz TPM (available only in China). Optional Lenovo Business
Vantage security software (available only in China).
Operating
systems
Microsoft Windows Server 2012 R2 and 2016; Red Hat Enterprise Linux 6 (x64) and 7; SUSE Linux
Enterprise Server 11 (x64) and 12; VMware vSphere (ESXi) 6.0, 6.5, and 6.7.
Warranty One-year (7X05) or three-year (7X06) customer-replaceable unit (CRU) and onsite limited warranty with
9x5 Next Business Day Parts Delivered.
Service and
support
Optional Lenovo Services upgrades: 2-hour or 4-hour response time, 6-hour or 24-hour committed
service repair, warranty extension up to 5 years, 1-year or 2-year post-warranty extensions, YourDrive
YourData, Enterprise Server Software Support, and Basic Hardware Installation Services.
Dimensions Height: 87 mm (3.4 in), width: 445 mm (17.5 in), depth: 720 mm (28.3 in)
Attribute Specification
