Chapter 2. 2-10
Step 3: Remove the base and stand from the monitor, refer to "Detaching the monitor base
and stand" on page 2-9.
Step 4: Connect all cables on the back of the monitor.
Step 5: Attach the mounting bracket from the VESA compatible wall mounting kit (100mm
x100mm distance), the type of VESA mounting screw is M4 x 10 mm.
Step 6: Attach the LCD display to the wall, and follow the instructions in the wall-mounting
kit.
Only use Wall Mount Bracket in the UL list with minimum weight/load: 8kg.
VESA hole
VESA hole
VESA
To Next Page
