Lenz Digital Plus STANDARD PLUS V2 User Manual

39
E
57
-
59,
61
Function mapping:
Each bit of the CV stands for a function of the digital system:
Bit 1(0) for function 1, Bit 2(1) for function 2 and so on up to
Bit 8(7) for function 8. If you wish to allocate a function to the
dimming, the respective bit must be set.
57
0-255
Mapping of Dimming for F-Outputs A to D (no ex-works setting)
0
58
0-255
Shunting speed (ex-works setting F3)
4
59
0-255
Switching off the delay (ex-works setting F4)
8
60
0-255
Lighting effect at function outputs A and B:
0
The tens digit for function
output B:
The units digit of the value
stands for function output A
0 No effect
1 Marslight
2 Gyrolight
3 Strobe
4 Double strobe
0 No effect
1 Marslight
2 Gyrolight
3 Strobe
4 Double strobe
61
0-255
Function mapping: lighting effect at function outputs A and B
0
62
0-255
Lighting effect at function outputs C and D.
0
The tens digit of the value stands
for function output D:
0 No effect
1 Flashing at same time as
function output C
2 Flashing alternately to function
output C
The units digit of the value
stands for function output C:
0 No effect
1 Flashing
2 Flickering type 1
(smooth)
