Lenz Digital Plus STANDARD PLUS V2 User Manual

38 Information STANDARD+ V2 Decoder
47
0-31
Function 1 backward
1
2
4
8
4
50
Bit
Motor configuration
0 (dec)
1-4 (0-3)
Select motor type 0-5, enter as decimal number
6 (5)
0 EMF switch inactive
1 EMF switch active
0
7 (6)
0 Control switched on
1 Control switched off
0
8 (7)
0 High-frequency motor control (approx. 23 kHz)
1 Low-frequency motor control (approx. 19 Hz)
0
51
Bit
Braking configuration
0 (dec)
1 (0)
1 Constant braking distance with ABC activated
0
2 (1)
1 ABC activated
0
3 (2)
1 ABC direction-dependency deactivated
0
4 (3)
1 Activate push-pull operation without intermediate stop
0
5 (4)
1 Activate push-pull operation with intermediate stop
0
6 (5)
1 Stopping with DC independent of the polarity (only if Bit 3 is
deleted in CV29).
0
7 (6)
Not used
8 (7)
1 Constant braking distance with speed step 0 activated
52
0-255
Braking distance with activated constant braking distance
50
53
0-255
Slow approach with ABC
48
54
0-255
Stopping time in push-pull operation, 1 to 256 sec
4
55
0-255
Sets brightness at function outputs A 255=max
255
56
0-255
Sets brightness at function outputs B 255=max
255
