Lenze 533*E 3A series - Page 13

11
l
RFI filter (V
max
= 250 V ±0 %)
a
bd
e
f
g
c
h
Design A
e
d
b
c
f
a
Design B
Types Filter
[Type]
Desi
gn
a
[mm
]
b
[mm
]
c
[mm
]
d
[mm
]
e
[mm
]
f
[mm
]
g
[mm
]
h
[mm
]
Fixing
531...53
3
EZF1_004A001 A 91.5 70 40 51 63.5 30 33 60.4 2 x M4
534 EZF1_018A001 B 116 85 39 108 50.8 100 - - 4 x M6
