I/O data transfer (implicit messages)
Technology applications (TA) / drive profiles
50
Lenze · Decentralised frequency inverter 8400 motec (EtherNet/IP™ option) · EDS84DMOTEIP EN 3.0 - 02/2019
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
8.3.2 "AC Drive Profile" application
The Inverter Drives 8400 motec supports the EtherNet/IP-specific "AC Drive Profile".
The standard device code C00005 = "1100: AC Drive Profile" serves to select the "AC Drive Profile"
application.
The "AC Drive Profile" contains ...
• the data basis for motor parameters,
• management functions of the motor control devices,
• Device-specific functions of the inverter, e.g. speed ramps, torque control etc.
For using the "AC Drive Profile", the following assembly object instances in the host (scanner) have
to be used:
See also:
• Assembly Object (4 / 0x04)
( 114)
• "AC Drive Profile" objects
( 133)
Tip!
Here you will find information on configuring with the »RSLogix 5000« programming
software from Rockwell:
I/O configuration with »RSLogix 5000« version 19 or lower
( 58)
I/O configuration with »RSLogix 5000« version 20 or higher
( 63)
Instance ID Assembly object instance
[dec] [hex]
20 0x14 Basic Speed Control Output Outputs: From the scanner to
the adapter
21 0x15 Extended Speed Control Output
22 0x16 Speed and Torque Control Output
23 0x17 Extended Speed and Torque Control Output
70 0x46 Basic Speed Control Input Inputs: From the adapter to
the scanner
71 0x47 Extended Speed Control Input
72 0x48 Speed and Torque Control Input
73 0x49 Extended Speed and Torque Control Input
Reference manual/»Engineer« Online help for the Inverter Drive 8400 motec
Here you can find detailed information on how to use the "AC Drive Profile".
