Error messages
Mapping of Lenze device errors to DRIVECOM errors
90
Lenze · Decentralised frequency inverter 8400 motec (EtherNet/IP™ option) · EDS84DMOTEIP EN 3.0 - 02/2019
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
xx.0184.00001 Ck01: Pos. HW limit switch 0x8600 0x8600 Positioning controller
xx.0184.00002 Ck02: Neg. HW limit switch 0x8600 0x8600 Positioning controller
xx.0184.00005 Ck15: Error message sig. brake 0x8600 0x8600 Positioning controller
xx.0184.00007 Ck03: Pos. SW limit position 0x8600 0x8600 Positioning controller
xx.0184.00008 Ck04: Neg. SW limit position 0x8600 0x8600 Positioning controller
xx.0184.00015 Ck14: Target position outside SW limit
position
0x8600 0x8600 Positioning controller
xx.0184.00064 Ck16: Time overrun manual operation 0x8600 0x8600 Positioning controller
xx.0184.00153 Ck05: Error following error 1 0x8611 0x8611 Following error
xx.0184.00154 Ck06: Error following error 2 0x8611 0x8611 Following error
xx.0184.00155 Ck07: Traversing range limit exceeded 0x8612 0x8612 Reference limit
xx.0184.00156 Ck08: Reference position unknown 0x8612 0x8612 Reference limit
xx.0184.08005 Ck09: Positioning mode invalid 0x8600 0x8600 Positioning controller
xx.0184.08007 Ck10: Profile data implausible 0x8600 0x8600 Positioning controller
xx.0184.08009 Ck11: Operating mode invalid 0x8600 0x8600 Positioning controller
xx.0184.08014 Ck12: Profile number invalid 0x8600 0x8600 Positioning controller
xx.0184.08015 Ck13: Error FB MCKCtrlInterface 0x8600 0x8600 Positioning controller
xx.0400.00009 dH09: EEPROM power unit 0x5530 0x7600 Data memory
xx.0400.00016 dH10: Fan failure 0x5000 0x5000 Device Hardware
xx.0400.00104 dH68: Adjustment data error CU 0x5530 0x6000 Device software
xx.0400.00105 dH69: Adjustment data error BU 0x5530 0x6000 Device software
xx.0980.00001 User error 1 0x6200 0x6200 User software
xx.0981.00002 User error 2 0x6200 0x6200 User software
xx.0982.00003 User error 3 0x6200 0x6200 User software
xx.0983.00004 User error 4 0x6200 0x6200 User software
xx.0984.00001 User error 5 0x6200 0x6200 User software
xx.0985.00002 User error 6 0x6200 0x6200 User software
xx.0986.00003 User error 7 0x6200 0x6200 User software
xx.0987.00004 User error 8 0x6200 0x6200 User software
Lenze error CAN DRIVECOM error
Error number
[32 bits]
Error message Emergency
Error Code
Error number
[hex]
Error message
