Configuration
7-246
SHB9300CRV EN 2.0
Fault message Possible reactions
Display CodeoffQWMTMeaning
OH Heatsink temperature 1 (max. permissible, fixed)
-
- - - - -
OH3 Motor temperature 1 (max. permissible, fixed)
-
- - -
T
C0583
OH4 Heatsink temperature 2 (adjustable; C0122) - -
-
-
T
C0582
OH7 Motor temperature 2 (can be set; code: C0121) - -
-
-
T
C0584
OH8 Motor temperature (fixed) via inputs T1/T2
T
-
T
*
-
-
C0585
OU Overvoltage on the DC bus -
-
- - - -
P01 Limit switch negative = LOW
T
- -
-
- C1285/1
P02 Limit switch positive = LOW
T
- -
-
- C1285/2
P03 Contouring error - digital frequency > C0255
T
-
-
-
T
C0589
P04 Position limit negative exceeded
T
- -
-
- C1285/3
P05 Position limit positive exceeded
T
- -
-
- C1285/4
P06 No reference
T
- -
-
- C1287/1
P07 Parameter set mode absolute
T
- -
-
- C1291/1
P08 Actaul offset out of range
T
- -
-
- C1291/2
P09 Impermissible programming
T
- -
-
- C1291/3
P12 Encoder range exceeded
T
- -
-
- C1288/1
P13 Phase overflow
-
-
T
-
T
C0590
P14 1. contouring error POS > C1218/1
T
-
T - T
C1286/1
P15 2. contouring error POS > C1218/2
T
-
T T -
C1286/2
P16 Sync error
T
-
T - T
C1290/1
P17 TP control error
T
-
T - T
C1289/1
P18 Internal limitation
T
-
- T T
C1289/2
PEr Program error
-
- - - - -
PI Fault during initialization
-
- - - - -
PR0 General fault in parameter sets
-
- - - - -
PR1 Fault in parameter set 1
-
- - - - -
Sd2 Resolver fault
-
-
T
*
-
T
C0586
Sd3 Encoder fault at X9 PIN 8
T
-
T
*
-
-
C0587
Sd5 Encoder fault at X6/1 X6/2 (C0034 = 1)
T
-
T
-
-
C0598
Sd6 Sensor fault: motor temperature (X7 or X8)
-
-
T
-
T
C0594
Sd7 Fault in the absolute value encoder at X8
T
- - -
-
C0025
TTRIP
-
Lenze
M Message
T
possible
W Warning - not possible
QFault/QSP
T
* possible, the drive may be destroyed if the fault is not eliminated in time
