Configuration
7-2

SHB9300CRV EN 2.0
7.2 Operating modes
Determine the operating mode, the interface you want to use for parameter setting or control of the
controller by choosing an operating module.
7.2.1 Parameter setting
Parameter setting via
l
Communication module (connected to X1)
– 2102 (LECOM A/B/LI)
– 2111 (INTERBUS)
– 2131 (PROFIBUS)
l
System bus module (connected to X4)
– 2173
l
Parameters can be changed by both interfaces.
7.2.2 Control
Controlispossibleviaterminals(X5and X6), viathefieldbus moduleat X1orvia thesystem bus(X4).
Mixed modes are also possible.
Note!
C0005 contains predefined configurations which allow a very easy change of the operating mode.
7.2.3 Configuration with Global Drive Control
With the PC program Global Drive Control (GDC) LENZE offers
l
an easy to understand,
l
well structured,
l
convenient
tool for the configuration of your specific drive task.
Function block library
l
GDC provides an easy-to-read library of available function blocks (FB).
l
GDC also displays the complete assignment of a FB.
Signal configuration
The signal configuration is done with only one dialog box. It is a convenient way
l
to display every FB as a block diagram.
l
to see the assignment of all signal inputs at a glance.
l
to enter the FB in the processing table.
l
to print your signal configuration.
Terminal assignment
Freely assignable terminals can be configured using two dialog boxes:
