Lenze EVS9326-EK

Configuration
7-8

SHB9300CRV EN 2.0
Create connections
1. Determine the signal source for ARIT2-IN1:
– Change to the code level using the arrow keys
– Select C0601/1 using
? or + .
– Change to the parameter level using PRG.
– Select output AIN2/OUT (selection number 55) using
? or + .
–ConfirmusingSH+PRG
– Change to the code level again using PRG.
2. Determine signal source for ARIT2-IN2:
– Select C0601/2 using
? .
– Change to the parameter level using PRG.
– Select output AIN2/OUT (selection number 55) using
? or + .
–ConfirmusingSH+PRG
– Change to the code level again using PRG.
3. Parameterise ARIT2:
– Select C0600 using
+ .
– Change to the parameter level using PRG.
– Select multiplication (selection number 3).
–ConfirmusingSH+PRG
– Change to the code level again using PRG.
4. Determine signal source for AOUT1:
– Select C0431 using
+ .
– Change to the parameter level using PRG.
– Select output ARIT2-OUT (selection number 5505).
–ConfirmusingSH+PRG
– Change to the code level again using PRG.
5. Enter function block ARIT2 in the processing table:
– Select C0465 and subcode 8 using
?
– Change to the parameter level using PRG.
– Enter function block ARIT2 (selection number 5505).
–ConfirmusingSH+PRG
– Change to the code level again using PRG.
– The sequence of the FB processing is thus determined.
