Function block library
7-40
SHB9300CRV EN 2.0
l
C0338 = 4
– Output = ARIT1-IN1 / |ARIT1-IN2|
– Example: 1% = 100% / 100%
l
C0338 = 5
– Output = ARIT1-IN1 / (100% - ARIT1-IN2)
– Example: 200% = 100% /(100% - 50%)
