Troubleshooting and fault elimination
8-2

SHB9300CRV EN 2.0
Display at the operating module
Status indications in the display indicate the controller status.
Display Controller status Check
RDY Controller ready for operation, controller can be inhibited C0183, C0168/1
IMP Pulses at the power stage inhibited C0183, C0168/1
I
max
Max. current reached
M
max
Max. torque reached
Fail Fault through TRIP, message, fail-QSP or warning C0183, C0168/1
Display via the LECOM status word C0150
Bit Meaning
0 FREE 0 freely linkable
1 IMP (pulse inhibit)
0 = enable pulses for power stage
1 = inhibit pulses for power stage
2 FREE 2 freely linkable
3 FREE 3 freely linkable
4 FREE 4 freely linkable
5 FREE 5 freely linkable
6 f
d
=0(act.speed=0) 0=n<>0
1=n=0
7 Ctrl. inhibit (controller inhibit) 0 = no controller inhibit
1 = controller inhibit
8-11 Controller status 0 = controller initialization
1 = switch-on inhibited
3 = operation inhibited (controller inhibit)
6 = operation enabled
7 = message active
8=faultactive
9 = power off
A = fail-QSP
12 Wa r n i ng 0=nowarning
1=warning
13 Message 0 = no message
1 = message
14 FREE 14 freely linkable
15 FREE 15 freely linkable
