Application examples
15-1
 SHB9300CRV EN 2.0
15 Application examples
15.1 Replacement of a mechanical cam
X
ϕ
X
ϕ
L
13.53
Hz
ϕ
X
+U GL1 L2 L3
X7
-U G U V W
X4
HI LO GND
X5
28 E1 E2 E3 E4 E5 39 A1 A2 A3 A4 59
93XX
X9
=
- 24V
M
RS
3
9
+
Selection of the configuration
l C0005 = 10000
Features
– Optimum adaptation to the process
– Easy changeover in the event of product changes
– Master value via incremental encoder
