Features
The following gure provides an overview of the elements and connecons on the product.
Their posion, size and appearance may vary.
Motor connection
Torque plate mounting
(depending on the mounting position)
Oil filler plug
(depending on the mounting position)
Ventilation
(depending on the mounting position)
Oil control plug
Torque plate mounting
(depending on the
mounting position)
Oil drain plug
Housing type
Output flange
Output shaft
Brake
Cooling
Feedback
Temperature monitoring
(depending on the
mounting position)
Oil drain plug
Product informaon
Features
17
