Lenze g500-B1500 Mounting And Switch-On Instructions

HAN modular 16 A pin assignment
Module Contact Name Meaning Illustraon
a
1 U1 Motor winding phase
4
5
6
3
2
1
a
c
a
b
c
4
5
6
3
2
1
2 V1
3 W1
b Blank module
c
1 TCO
+PT1000
Temperature monitoring
2 +/AC Brake
3 -/AC
4 Switching contact
Recer
5
6 TCO
-PT1000
Temperature monitoring
HAN modular 40 A pin assignment
Module Contact Name Meaning Illustraon
a
1 U1 Motor winding phase
4
5
6
3
2
1
1
2
3
4
5
6
3
2
1
a
c
a
b
c
2 V1
3 W1
b Blank module
c
1 TCO
+PT1000
Temperature monitoring
2 +/AC Brake
3 -/AC
4 Switching contact
Recer
5
6 TCO
-PT1000
Temperature monitoring
Anschluss über M12-Steckverbinder (neu)
M12 pin assignment
Incr. encoder IG128-24V-H
Contact Name Meaning
1
+ U
B
Supply +
1
2
4
3
2 B Track B
3 GND Mass
4 A Track A
Electrical installaon
Motor connecon
Anschluss über M12-Steckverbinder (neu)
48
