Maintenance
Maintenance operations
Position of the lubricant monitoring elements
7
57
Lenze ¯ MA 12.0019 ¯ 6.1
Mounting position M4[C] Mounting position M5[E] Mounting position M6[F]
+
Filling Drain
Breathing Control
The shown oil bores are optional for gearbox size g500−B240!
