7.3.3 Checking the oil level
) Note!
Check the oil level in cold condition!
Check the oil level by means of the displayed dipsticks. Manufacture them according to
the mounting position.
Form template: dipsticks for g500−B240/G50BB124
[mm]
0
10
100
50
M6
M5
M2
M4
M3
M1
M1
3
4
+
2
