EtherCAT
Notes on the EtherCAT connecon status and the data transfer can be obtained via the LED "L/A" at the RJ45
sockets.
LED "L/A"
Blinking paern State Meaning
o Not connected Network not available
on
Connected Network available
No data transfer
blinking
Trac Data transfer
Typical topologies
Line
IN OUT
M
R
SDn
SD2
SD1
IN OUT IN
M Master
SD Slave Device
Bus-related informaon
Name EtherCAT
Communicaon medium Ethernet 100 Mbps, full duplex
Use Connected as EtherCAT slave
Status display 2 LEDs (RUN, ERR)
Basic network sengs
The rotary encoder switch allows you to set an EtherCAT idener.
Seng Idener
0x00 Value from parameter
0x01 ... 0xFF Switch posion
Electrical installaon
Networks
EtherCAT
90
