3.5 Command Station (CS) design
Elements
Status
F1
Fail
+
-
F3
F2
Power
0
1
8
7
6
5
4
PS/2
LAN
RS232
ACU UPS
24 V DC
CF Card
MC Card
Reset
USB
23
9
CS57x0−001
Pos. Description
0 Command Station (IPC, here CS 5800)
Command Station TC (Thin Client)
Command Station DVI (monitor panel)
1 Mounting frame with VESA−100 adapter surface
2 PC or monitor control for the monitor panel
3 Screen
4 Front face control and display elements
5 Front face USB port (option)
6 Mounting frame connecting plate (option)
Overview
Command Station CS 5800 / CS 9800
Command Station CS 5800 TC / CS 9800 TC
Command Station CS 5000 DVI / CS 9000 DVI
-
F3
Fail
Power
F1
+
F2
Status
l CS 5800 (TC): XGA touchscreen 38.1 cm (15")
CS 9800 (TC): SXGA touchscreen 48.3 cm (19")
l CS 5000 DVI: XGA touchscreen 38.1 cm (15")
CS 9000 DVI: SXGA touchscreen 48.3 cm (19")
l 3 freely assignable function keys
CS57x0−026
