3 Commissioning
EDBZAEBK000X DE/EN/FR/ES/IT 4.0
32
H1inbet−E94AZKAE_Inbetriebnahme_EN
Step−by−step commissioning
Commissioning step Comment
1. Connect keypad to the diagnostic interface. You can also connect or remove the keypad
during operation.
2. If the keypad is supplied with voltage, it
carries out a short self test.
3. The keypad is ready for operation if it
displays the main menu.
If you commission the keypad for the first
time, you are requested to select the dialog
language.
4. You can now communicate with the basic
device.
How to navigate through the menus and how
to view and alter parameters can be learned
here: 33
