Integrated Lithium-ion Battery Pack For Telecom
All Right Reserved © LEOCH International Technology Limited
31
7 APPENDIX
7.1 Connection cable
If groups (4~10) of parallel sets of lithium batteries are not supplied by Leoch battery
racks, you can choose the customized wiring cables to replace. Relevant technical
requirements are the feeder cable number and the number of parallel battery pack is
consistent, and the specifications of each extension cable (length, diameter, and
material) are the same.
For example, a customised six parallel wiring cable diagram as shown in figure7-1.
Figure7-1 Customized wiring cable diagram
According to the customer requirements, selecting the appropriate connector, cables,
extension cable specifications, refer to relevant cable specifications given in table 7-1.
