LEONI eol 1x2 User Manual

REV 07a / 01_ 2012
10
Please note:
After each switching process the switch will not accept signals for the next 6 ms. Other values
are possible on costumers request.
(See the following table for the necessary binary code corresponding to the required switch
channels.
Please note that data pins D3 and D2 are not used for switch configurations 1x2; 2x2; 1x4).
D3
D2
D1
D0
Channel
0 0 0 0
1
0 0 0 1
2
0 0 1 0
3
0 0 1 1
4
0 1 0 0
5
0 1 0 1
6
0 1 1 0
7
0 1 1 1
8
1 0 0 0
9
1 0 0 1
10
1 0 1 0
11
1 0 1 1
12
1 1 0 0
13
1 1 0 1
14
1 1 1 0
15
1 1 1 1
16
