LEONI eol 1x2 User Manual

REV 07a / 01_ 2012
3
FUNCTIONAL BLOCK DIAGRAM
FEATURES
• excellent repeatability
• ultra low back reflection
• low insertion loss and PDL
• high optical isolation
• broad spectral range
• polarization maintaining option
• short switching time
• small dimensions
APPLICATIONS
• testing and measurement
• fiber optic sensing
• add/ drop multiplex system
• network fault protection
• signal protection
• laser scanning microscopy
• fiber bragg sensors
• multi channel optical power monitoring
TECHNOLOGY
eol
series switches were developed to serve for
the most demanding applications in testing and
measurement. Its optomechanical design
(MOEMS) ensures an excellent optical
performance combined with short switching time
due to refractive microoptical componen
ts and
industry proofed high resonant actuators. The
small package size and unilateral fiber location
simplify the switch accomodation on printed
circuit boards. The implemented microcontroller
provides versatility in interface programming and
controlling.
opto
-
mechanical
system
actuators
MICRO-
CONTROLLER
RS232
I
2
C
parallel
interface
electronic interfaces and controller
VCC GND
RxD
TxD
D0
D1
Strobe
SDA
SCL
Ch1
Input
Ch4
Ch3
Ch2
