LEONI eol 1x2 - Optical Performance Specifications; Electrical and Environmental Specifications

REV 07a / 01_ 2012
4
OPTICAL CHARACTERISTICS
parameter
unit
test conditions / comments
insertion loss 0.7 dB typ.
@ 1.55µm and 1,31µm
1.0 dB max.
1.4 dB max. @ 0.80µm and 0,65µm
2.0 dB max @ 0.46µm … 0.60 µm
back reflection <-65 dB @ 1,55µm
crosstalk <-55 dB
repeatabiltiy 0.005 dB
5000 cycles @ 1Hz, constant
temperature
standard wavelength range 400…670 nm
600...850 nm
other wavelengths on request
900…1200 nm
1260 - 1360
1480 - 1650
nm
polarization depending loss < 0.1 dB
switching time
switching frequency
≤2
50
ms
Hz max.
reliability > 10
8
cycles
power consumption < 300 mW
ELECTRICAL
CHARACTERISTICS
parameter
unit
test conditions / comments
operating voltage 5 V
switching current 50 mA min. switching frequency = 0Hz
100 mA typ.
300 mA max. switching frequency = 50Hz
ENVIRONMENTAL CHARACTERISTICS
parameter
unit
test conditions/comments
storage temperature -40 to +80 °C
operating temperature 0 to +60 °C
vibration stability Up to 10 g
no influence on optical
characteristics
