Prime Series 19 of 20 User’s Manual
16. SPECIFICATIONS
AC Input
Voltage range, rated 100-230 Vac
Voltage range, operating 85-265 Vac
(< 100 Vac: reduced power)
Frequency, rated 50-60 Hz
Frequency, operating 45-65 Hz
Phase Single-phase
Current, maximum 4 A
Protection Current limit, surge, transient, under voltage
DC Output
Voltage, nominal 24 Vdc
Voltage, maximum 36 Vdc
Voltage, minimum start-up 3 Vdc
Power 350 W
Current, rated 12 A
Current, maximum 12 A
Battery types Wet/flooded, AGM, gel deep-cycle lead-acid; lithium-ion; custom. (See
Section 3.)
Protection Current limit, short circuit, reverse polarity, under voltage, over voltage,
wrong battery voltage
LED Single Multi-color LED,
Amber (charge status), Green (charge complete), Red (fault)
Lockout SPDT dry-contact relay. 10 A continuous rating. See Section 8 for
options and additional details.
Remote LED Optional
Battery Temp Sensor Optional
Mechanical
Dimensions & mounting
pattern See Figures 2-1 through 2-3
Weight (approximate) 5.5 pounds
Cooling Natural convection (no fan)
AC connector IEC 60320 C14 inlet with cord clamp
Mounting Shelf, wall, bulkhead, See Figure 2-1 though 2-2 for additional details.
Environmental
Enclosure rating IP66, NEMA 4
Operating temperature -25 degrees C to 45 degrees C (-13 degrees F to 113 degrees F).
Storage temperature -40 degrees C to 80 degrees C (-40 degrees F to 176 degrees F)
