8
NOTE: To focus your GX rangefinder, turn the rubber eyepiece
left or right until crisp focus is achieved.
The GX-3c and GX-5c have two buttons: POWER and MODE. When
you initially press the POWER button, the display is activated and
the unit is ready for ranging. Press the POWER button a second
time to range, or press and hold the POWER button to scan.
Scanning automatically updates distance readings in the display.
When ranging long distances without a steady rest, you can easily
differentiate the pin from other potential targets behind it.
When you press and hold the MODE button for 2 seconds and
then release it, the Quick Set Menu is activated. To activate a
mode, you must advance to that function by pressing the MODE
button until the function is displayed. To set or manipulate a
1. Power
2. Focus
3. Battery
4. Mode
1
2
3
4
