7
Alarm sounds
WARNING
 Switch off the current to avoid electric shocks during installation or mainte-
nance work. Check the voltage. Only use modules and incandescent lamps
that specify the same voltage.
Switch
position
LEVEL 1
S1
Tone type
Frequency
Hz
Pictogram
Volume
dB
TONE 01 Continuous 970 97
TONE 02 Alternately 970 97
TONE 03 Alternately 1000 100
TONE 04 Alternately 970 98
TONE 05 Continuous 834 - 2143 95
TONE 06 Continuous 1100 - 2000 95
TONE 07 Continuous 724 & 1536 97
TONE 08 Alternately 796 - 2565 102
ON
OFF
Single-sound buzzerMulti-sound buzzer
