LevelOne FVT-2002 - Page 12

10
Optical Fiber
Module Name
Wavelength
Avg. Launch
Power
Avg.
Sensitivity
100Base-FX Fiber SC MM
1310 (nm)
>-21dBm
-31dBm
100Base-FX Fiber ST MM
1310 (nm)
>-21dBm
-31dBm
100Base-FX Fiber SC SM
20KM
1310 (nm)
>-15dBm
-34dBm
100Base-FX Fiber SC SM
40KM
1310 (nm)
>-10dBm
-37dBm
1000Base-SX Fiber SC MM
850 (nm)
>-10.5dBm
-20dBm
Module Name
Avg. Power
Loss Budget
Max. FDX
Fiber
Distance
Fiber Size (um)
100Base-FX Fiber SC MM
10 (dBm)
2 (Km)
62.5/125
50/125
100Base-FX Fiber ST MM
10 (dBm)
2 (Km)
62.5/125
50/125
100Base-FX Fiber SC SM
19 (dBm)
20(Km)
9/125
8/125
100Base-FX Fiber SC SM
27 (dBm)
40(Km)
9/125
8/125
1000Base-SX Fiber SC MM
9.5 (dBm)
550 (m)
62.5/125
50/125
