2.3. LED Indicators
Fast Ethernet Module
LED
Status
Meaning
PWR
On
Power on
FX 100
On
100Mbps Fiber Speed
TX 100
On
100Mbps UTP Speed
OFF
10 Mbps UTP Speed
FDX
On
Converter works in the full duplex mode
OFF
Converter works in the half duplex mode
FX
LINK/ACT
On
Connection status display for fiber link.
“ON” indicates that Fiber link is in correct
connection.
Blinks
Active status display of fiber link
“Blink” indicates packet goes through FX end.
TX
LINK/ACT
On
Connection status display for electric link.
“ON” indicates that electric link is in correct
connection.
Blinks
Active status display of fiber link
“Blink” indicates packet goes through TX end
