Optical Fiber
Module Name
Wavelength
Avg. Launch
Power
Avg.
Sensitivity
100Base-FX Fiber SC MM
1310 (nm)
>-21dBm
-31dBm
100Base-FX Fiber ST MM
1310 (nm)
>-21dBm
-31dBm
100Base-FX Fiber SC SM
20KM
1310 (nm)
>-15dBm
-34dBm
100Base-FX Fiber SC SM
40KM
1310 (nm)
>-10dBm
-37dBm
100Base-FX Fiber SC SM
20KM
1310/1550
(nm)
>-10dBm
-34dBm
1000Base-SX Fiber SC MM
850 (nm)
>-10.5dBm
-20dBm
1000Base-SX/LX Fiber SC
SM 20KM
1310 (nm)
>-8dBm
-23dBm
1000Base-SX/LX Fiber ST
SM 20KM
1310 (nm)
>-8dBm
-23dBm
Module Name
Avg. Power
Loss Budget
Max. FDX
Fiber
Distance
Fiber Size (um)
100Base-FX Fiber SC MM
10 (dBm)
2 (Km)
62.5/125
50/125
100Base-FX Fiber ST MM
10 (dBm)
2 (Km)
62.5/125
50/125
100Base-FX Fiber SC SM
19 (dBm)
20(Km)
9/125
8/125
100Base-FX Fiber SC SM
27 (dBm)
40(Km)
9/125
8/125
100Base-FX Fiber SC
SM1310/1550 (nm)
24 (dBm)
20(Km)
9/125
8/125
1000Base-SX Fiber SC MM
9.5 (dBm)
550 (m)
62.5/125
50/125
1000Base-SX/LX Fiber SC
SM
15 (dBm)
20(Km)
9/125
1000Base-SX/LX Fiber ST SM
15 (dBm)
20(Km)
9/125
