3. Perform Initial Configuration
1. Connect a PC to the switch console port using the included console cable.
2. Configure the PC’s serial port: 115200 bps, 8 characters, no parity, one stop bit, 8 data bits,
and no flow control.
3. Log in to the CLI using default settings: Username “admin” and password “admin.”
4. Logging on to the equipment
1.
Connect the RJ-45 interface cable of a switch with a computer using a network cable.
2.
Set the TCP/IP properties of the computer, see the Appendix: Setting up yourcomputer.
3.
Logging on to the equipment: Open a browser and type 192.168.1.1 in the address bar, and
then press Enter; in the pop-up login interface, enter the factory logon username "admin",
password "admin" and click OK.
Note:
For further information on switch configuration, refer to the Web Management
Guide and CLI Reference Guide.
