LevelOne HVE-9005 - SPECIFICATIONS

2
SPECIFICATIONS
Model Name
HDMI over Cat.5 Extender Kit
Model No.
HVE-9005T
HVE-9005R
ProductName
HDMI over Cat.5 Transmitter
HDMI over Cat.5 Receiver
HDMI compliance
HDMI Deep Color, full 3D & 4K2K@30
HDCP compliance
Yes
Video bandwidth
Single-link 340MHz [10.2Gbps]
Video support
480i / 480p / 720p / 1080i / 1080p60
HDMI over UTP
1080p@60 60m (198ft) [CAT5e]
Audio support
Surround sound [up to 7.1ch) or stereo digital audio
Equalization
Auto
Input TMDS signal
1.2 Volts [peak-to-peak]
Input DDC signal
5 Volts [peak-to-peak, TTL]
ESD protection
[1] Human body model — ±19kV [air-gap discharge] & ±12kV [contact
discharge]
[2] Core chipset — ±8kV
PCB stack-up
4-layer board [impedance control — differential 100Ω; single 50Ω]
IR pass-thru
Bi-directional
Input
1x HDMI
1x 3.5mm
1x mini-USB
1x RJ-45[HDBaseT]
1x 3.5mm
1x mini-USB
Output
1x RJ-45[HDBaseT]
1x 3.5mm
1x HDMI
1x 3.5mm
HDMI source control
Controllable via IR pass-through from R to T with IR extenders
HDMI connector
Type A [19-pin female]
USB connector
Mini B
RJ-45 connector
WE/SS 8P8C(Reverse Mode)
Rotary control switch
None
3.5mm connector
IR receiver / IR blaster
IR receiver / IR blaster
Mechanical
HVE-9005T
HVE-9005R
Housing
Metal enclosure
Dimensions [L x W x H]
73 x 89 x 26mm [2.9" x 3.5" x 1"]
Weight
200g [7oz]
196g [6.9oz]
Fixedness
Wall-mounting case with screws
Power supply
5V 2A DC
Power consumption
3 Watt [max]
7 Watt [max]
Operation temperature
0~40°C [32~104°F]
Storage temperature
-20~60°C [-4~140°F]
Relative humidity
20~90% RH [no condensation]
