③ IR OUT: Connect with IR Emitter.
④ HDMI OUT: Connect to display.
⑤ EQ SETTING: After the system is connected, press this button three to
six times repeatedly until the best image output. When the cable, source,
or display is changed, or reset the output resolution, it is need to press this
button repeatedly to ensure the best image.
Specifications
Transmitter
Receiver
Input
(1) HDMI
(1) CAT
Input Connector
(1) 19-pin type-A female
HDMI
(1) RJ45
Output
(1) HDMI; (1) CAT
(1) HDMI
Output
Connector
(1) 19-pin type-A female
HDMI, (1) RJ45
(1) 19-pin type-A
female HDMI
Control
(1) IR IN, (1) IR OUT
(1) IR IN, (1) IR OUT
Control
Connector
(2) 3.5mm mini jacks
(2) 3.5mm mini jacks
General
Transmission
Distance
1080p@60Hz≤50m (CAT6)
HDMI Standard
HDMI 1.3, HDCP 1.4 compliant
EDID
Management
Built-in EDID
