Microscope assembly
Take the microscope and all accessories out of the package. Place the stage on a stable surface.
Attach the mount locking ring (6) to the metal tube of the mount. Insert the metal tube into
the opening on the stage and lock it in place with the ring (6).
Insert the microscope into the clamp on the mount arm and tighten the locking screw (5).
Tighten the locking knob (4) to lock the mount arm in place.
Focusing
Place a specimen on the stage and use the coarse focus knob (1) to focus your view.
Use the fine focus knob (3) for maximum precision and sharpness.
Upon focusing your view, tighten the focus lock knob (2) to lock the results.
