Levoit VortexIQ 40 User Manual

7
USING YOUR VACUUM
1. Attach the vacuum head or nozzle
attachment to the bottom of the stick and
attach the vacuum body to the top of the
stick [Figure 1.1].
Figure 1.1
Battery Level Battery Indicator
70–100% 3 lights
50–70% 2 lights
20–50% 1 light
0–20% 1 flashing light
Note: There is a clicking sound when the
parts are properly joined together.
Note: Fully charge the battery before
first use.
2. Charge the vacuum (see page 10).
3. Press the On/O Trigger to turn the
vacuum on.
4. Press to use Auto Mode, or press
or to manually control suction
power.
5. Press the On/O Trigger to turn the
vacuum o.
Battery Indicator Light Chart
(During Use)
Nozzle Attachments
Your vacuum comes with nozzle attachments
to help you tackle almost any cleanup job.
Telescoping Crevice Tool
• Press button to extend the crevice
nozzle [Figure 1.2].
• Use to clean hard-to-reach places.
• Good for reaching small cracks and
crevices in furniture, the corners of a
room, or a car.
Figure 1.3
Figure 1.2
2-in-1 Dusting Brush
• Press button to slide bristles up/down
and switch between upholstery brush
and duster [Figure 1.3].
• Use upholstery brush to clean soft
furnishings and upholstery.
• Use bristles to dust and clean hard
surfaces.

Levoit VortexIQ 40 Specifications

General

Brush shape	Rectangular
Product type	Stick vacuum
Dust capacity	0.6 L
Product color	Gray
Dust container type	Bagless
Removable handheld vacuum	Yes
Cleaning type	Dry
Vacuum air filtering	HEPA
Dirt separating method	Cyclonic
Air filtration stages quantity	4
Motor power	400 W
Power source	Battery
Charging time	5 h
Suction power	130 AW
Battery voltage	25.9 V
AC input voltage	100 - 240 V
Battery capacity	2500 Ah
AC input frequency	50 - 60 Hz
Maximum input power	- W
Vacuum brushes included	Dusting brush

Weight and Dimensions

Depth	230 mm
Width	250 mm
Height	1170 mm
Weight	3200 g
