Lewis Resto - Step-by-Step Assembly Instructions; Step One: Attaching Headboards; Step Two: Attaching Side Rails

2
1
2
A
D
C
C
F
F
F
A
D
2
2
3
A
A
G
G
Left
Right
Step by step assembly instructions
3/5
Attach the Headboards (2) to the Back Panel (1) using JCBC Screw M6 x 20mm (A), M6 JCN
Nut (D) and JCBC Screws M6 x 35mm (C). Tighten using Allen Key (F).
Attach the Side Rail (3) to the Headboards (2) using JCBC Screw M6 x 20mm (A) and Washer (G).
Tighten using Allen Key (F).
Step One
Step Two
