Lewmar V3 - V1-6 Wiring diagram

Lewmar V1-6 Windlass ref 65001201 iss.8 | 13
Thermal Switch (IF tted)
Reed Switch Sensor for Chain Counter (If tted)
Circuit Breaker
Battery
Isolator
Battery
12/24 VDC
Contactor
Electric Deck
Switches
Rocker
Switches
Electric Remote
Control
Thermal
Switch
Fuse
3 A
V1-3 & 5
4
5
4
5
4 5
1
2
3
1
2
3
UP
DOWN
UP
DOWN
Control Box
1
2
3
2
1
−V
BATT +VE
MOTOR D2
MOTOR D1
D1
D2
A2
BAT T
+VE
MOTOR
F1
MOTOR
F2
D1
D2
A2
5.5 V1-6 Wiring diagram
Installation instructions are supplied separately with any accessories.
1. NOTE: Motor connections
D1 = F1
D2 = F2
2. Switch wire thickness:
1.5 mm2 (16 AWG)
