Installation and Audio Connections
1-3
Power Switch
and Indicator
The Power Switch turns
the 480L on and off; the
indicator lights when the
unit is on. A lithium battery
retains the data memory
when power is off or
disconnected.
480L Front Panel
About the Front Panel
Front Panel Latch
The front panel is hinged
at the bottom; pull on the
handle to open. Keep the
front panel closed during
normal operation to
maintain dust filtration.
Cartridge Slot
The Cartride Slot accepts
both ROM-based program
cartridges, and Nonvolatile
RAM cartridges for
additional memory
storage.
The 480L is shipped with
one Nonvolatile Memory
Cartridge, providing five
banks of portable register
storage. A write-protect
switch prevents accidental
erasure of contents.
