LFE (ON, OFF)
LFE (Low Frequency Enhancement) activates and deactivates the
MAIN AUDIO OUTPUT labelled LFE. Selecting this parameter
accesses the pulldown menu pictured above. Use the up and down
MENU arrows to switch between the ON and OFF settings. Press
the right MENU arrow to select the desired setting. Press the left
MENU arrow to close the pulldown menu and return to the
CUSTOM SETUP menu.
When the LFE parameter is set to ON, the unit sends the LFE
channel to the LFE output. When set to OFF, the unit deactivates
the LFE output and sends the LFE channel to the SUBWOOFER L/R
outputs. If the SUBWOOFER L/R outputs are set to NONE, the LFE
channel is sent to the MAIN AUDIO OUTPUTS with the lowest
crossover setting.
3-23
The SETUP Menu
MC-12/MC-12 Balanced
For example, LFE is set to OFF, SUBWOOFER L/R is set to NONE,
FRONT L/R is set to 40Hz, and the rest of the MAIN AUDIO
OUTPUTS are set to 60Hz. The LFE channel will be sent to the
FRONT L/R outputs, utilizing the 40Hz crossover point.
SETUP
INPUTS
SPEAKERS
REAR PANEL CONFIG
DISPLAYS
VOLUME CONTROLS
TRIGGERS
LOCK OPTIONS
MAIN MENU
MODE ADJUST
AUDIO CONTROLS
SETUP
CUSTOM SETUP
FRONT L/R 40Hz
CENTER 60Hz
SIDE L/R 60Hz
REAR L/R 60Hz
SUB L/R MONO
SUB XOVER 40Hz
LFE
OFF
SPEAKER SETUP
CUSTOM SETUP
THX SETUP
SPEAKER DISTANCES
LEVELS CALIBRATION
