Data Type: Signed 8 bit integer (2’s compliment)
Max: +12 (0x0C) (12 dB)
Min: -80 (0xB0) (-80 dB)
Current Input:
Data Type: Unsigned 8 bit integer
Definition/Conversion: Appendix F MC-12 Input Ids
Current Effect Id:
Data Type: Unsigned 8 bit integer
Definition/Conversion: Appendix_H_MC-12_Effect_Ids
Current Input Sample Rate:
Data Type: Unsigned 8 bit integer.
SAMPLE RATE
RATE_UNKNOWN 0
RATE_44 1
RATE_48 2
RATE_88 3
RATE_96 4
Current Input Format:
Data Type: Unsigned 8 bit integer.
DATA STREAM TYPE
DATA_TYPE_UNKNOWN 0
DATA_TYPE_BYPASS 1
DATA_TYPE_ANALOG 2
DATA_TYPE_PCM 3
DATA_TYPE_DD 4
DATA_TYPE_DTS 5
DATA_TYPE_NOISE 6
Mute Active:
Data Type: Boolean.
TRUE: System Mute is Active
FALSE: System is unmuted.
Effect Bypass:
Data Type: Boolean
TRUE: Effect Bypass is Active
FALSE: Effect Bypass is Inactive
Left/Right Balance:
Data Type: Signed 8 bit integer (2’s compliment)
Max: 16 (0x10) (Full Right)
Min: -16 (0xF0) (Full Left)
Front/Back Balance:
Data Type: Signed 8 bit integer (2’s compliment)
Max: 16 (0x10) (Full Front)
