MC-12 Serial Communications Protocol Printed on: 07/19/04
© 2004 Harman Specialty Group All rights reserved. 60 of 102
Appendix E MC-1 Input Id’s
Input Name
Input Id
Tape
0
Tuner
1
Cd
2
Aux
3
TV
4
V-Disc
5
DVD
6
VCR
7
Appendix F MC-12 Input Ids
MC-12
Input Name
MC-12
Input Id
Mapped
MC-1
Input Name
OFF 0
N/A
DVD1 1
Aux
DVD2 2
Aux
LD 3
V-Disc
TV 4
TV
SAT 5
Aux
VCR 6
VCR
CD 7
CD
PVR 8
Aux
GAME 9
Aux
TAPE 10
TAPE
TUNER 11
TUNER
AUX 12
AUX
Appendix G Protocol Constants
Constant Value (Dec)
Units
FPD_LINE_LENGTH 20Chars
PARAM_NAME_LENGTH 13Chars
CUSTOM_NAME_LENGTH 20Chars
INPUT_NAME_LENGTH 8Chars
PARAM_PATH_LENGTH 80Chars
INTER_PACKET_TIME 200mSec
SOP 0xF1 Hex
EOP 0xF2 Hex
