Responses
DC_RESP_UNIT_CONFIG 0x80
DC_RESP_SYS_STATUS 0x81
DC_RESP_REC_ZONE2_STATUS 0x82
DC_RESP_SYS_PARAM_DEF 0x83
DC_RESP_SYS_PARAM_VALUES 0x84
DC_RESP_EFFECT_DEF 0x85
DC_RESP_EFFECT_PARAM_DEF 0x86
DC_RESP_EFFECT_PARAM_VALUES 0x87
DC_RESP_FPD_CTRL_STATUS 0x88
DC_RESP_CUST_NAME 0x89
DC_RESP_INPUT_NAME 0x8A
DC_RESP_PEEK_VALUE 0x8B
DC_RESP_COM_CONFIG 0x8C
MC_RESP_SYS_PARAM_DEF 0x8F
MC_RESP_UNIT_CONFIG 0x91
Acknowledgments
DC_ACK 0xE0
DC_NAK 0xE1
Appendix B Error Codes
Error Code(Hex)
NO_ACK 0x00
DC_NO_ERROR 0x01
DC_ERR_PARITY 0x02
DC_ERR_FRAMING 0x03
DC_ERR_OVERRUN 0x04
DC_ERR_INVALID_PACKET 0x05
DC_ERR_TIME_OUT 0x06
DC_ERR_BUFFER_FULL 0x07
DC_INVALID_COUNT 0x10
DC_INVALID_CMD 0x11
DC_INVALID_DATA 0x12
DC_INVALID_ADDRESS 0x13
DC_INVALID_EFFECT_ID 0x14
DC_INVALID_PARAM_ID 0x15
DC_INVALID_NAME 0x16
DC_INVALID_INPUT 0x17
DC_ERR_READ_ONLY 0x18
