MC-12 Serial Communications Protocol Printed on: 07/13/05
Parameter MC-12 Parameter Name
Current Mode
PARAM.MAIN.EFFECT
Main Zone Mute
PARAM.MAIN.MUTE
Main Zone Volume
PARAM.MAIN.VOLUME
Main Zone Balance
PARAM.MAIN.BALANCE
Main Zone Input Selection
PARAM.MAIN.INPUT
Zone 2 Input
PARAM.ZONE.INPUT
Zone 2 Volume
PARAM.ZONE.VOLUME
Zone 2 Balance
PARAM.ZONE.BALANCE
Zone 2 Mute
PARAM.ZONE.MUTE
Bass
PARAM.MAIN.BASS
Treble
PARAM.MAIN.TREBLE
Loudness
PARAM.MAIN.LOUDNESS
Tilt
PARAM.MAIN.TILT
Menu Background On/Off
PARAM.OSD.BACKGND
See
MC12 V5.00 Parameter ID List for the Parameter ID definitions.
7.2 Acknowledgment Packets
Acknowledge and No Acknowledge packets are used to communicate transmission, packet and data
validation status. Both the HOST and MC-12 can transmit and receive these packets.
7.2.1 Acknowledge (MC-12, MC-1)
7.2.1.1 Packet Description
Application Header:
Command DC_ACK 0xE0
Data Count 10x01
Application Data:
Data[0] Command nn
7.2.1.2 Data Description
Command:
DataType: Valid MC-12 command as defined in
Appendix A Command Codes.
© 2005 Harman Specialty Group All rights reserved. 16 of 106
