MC-12 Serial Communications Protocol Printed on: 07/13/05
7.3.4.2 MC-12 Unit Configuration Response Packet
Application Header:
Command DC_RESP_UNIT_CONFIG 0x80
Data Count 25 0x19
Application Data:
Data[0] ProductId nn
Data[1] Software Type nn
Data[2] Software Level nn
Data[3] Software Major Revision nn
Data[4] Software Minor Revision nn
Data[5] Protocol Major Revision nn
Data[6] Protocol Minor Revision nn
Data[7] N/A nn
Data[8] Total Number of Effects nn
Data[9] TimeStamp[0] ch
Data[10] TimeStamp[1] ch
Data[11] TimeStamp[2] ch
Data[12] TimeStamp[3] ch
Data[13] TimeStamp[4] ch
Data[14] TimeStamp[5] ch
Data[15] TimeStamp[6] ch
Data[16] TimeStamp[7] ch
Data[17] TimeStamp[8] ch
Data[18] TimeStamp[9] ch
Data[19] TimeStamp[10] ch
Data[20] TimeStamp[11] ch
Data[21] TimeStamp[12] ch
Data[22] TimeStamp[13] ch
Data[23] TimeStamp[14] ch
Data[24] TimeStamp[15] 0x00
7.3.4.3 Data Description
ProductId: This unsigned 8 bit value describes the product.
Product ID
Lexicon DC-2 1
Lexicon MC-1 2
JBL Synthesis SDP-3 3
Lexicon MC-12 4
JBL Synthesis SDP-40 5
© 2005 Harman Specialty Group All rights reserved. 19 of 106
