Getting Started
RT-10
1-9
The remote control requires two AA batteries that should be
replaced as needed. It is strongly recommended to use Alkaline
batteries, which last longer without leaking.
To replace the remote control batteries:
1. Locate the battery compartment on the back of the remote
control. Then, remove the battery compartment cover as
shown in Figure A (above). To do this, press the tab attached
to the cover. When the tab is pressed, pull the cover away from
the remote control.
2. Remove and dispose of old batteries inserted in the
compartment (if applicable).
3. Insert two AA batteries in the compartment as shown in Figure B
(above). Make sure the batteries are correctly inserted observing
the proper polarity.
4. When new batteries have been inserted, close the battery
compartment cover as shown in the Figure C (above). To do
this, align the cover with the guide on the back of the remote
control. Then, press the cover until it "snaps" into place.
5. It is recommended to refer to the Remote Control Overview
section that begins on page 2-14 before operating the remote
control.
REMOTE CONTROL BATTERY INSTALLATION
Figure A Figure B Figure C
