RV-5 Mode Adjust
6-17
5.1 PLIIx MUS
The 5.1 PLIIx MUS (MUSIC) listening mode is designed to playback 7.1
discrete channels decoded from 5.1-channel Dolby Digital music
sources. The seven main channels are full–frequency. The .1 channel,
often referred to as LFE information, has a limited frequency range of
up to 120Hz.
Note:
The RV-5 cannot detect Dolby Digital Surround EX encoding in
non-flagged 5.1-channel Dolby Digital input sources.
Activating the 5.1 PLIIx MUS listening mode
The 5.1 PLIIx MUS listening mode is a dynamic listening mode and
cannot be assigned as a preferred listening mode for Dolby Digital
sources. To activate this listening mode, use the front-panel or remote
control Mode buttons.
When the DOLBY D parameter is set to USE LAST, the RV-5 will
automatically activate the dynamic 5.1 PLIIx MUS listening mode if
this listening mode was activated the last time a Dolby Digital
source was present.
Note:
The 5.1 PLIIx MUS mode does not appear in the list of available listening
modes if either the side or rear speakers are missing from the configuration.
See “Listening Mode Menu Option and Parameter Descriptions” on page 6-30 for
detailed descriptions.
MODE ADJUST
5.1 PLIIx MUS
Parameter Default Setting Possible Settings
EX DECODING AUTO AUTO, ON, OFF
COMPRESSION OFF AUTO, ON, OFF
LFE MIX +0.0dB –10.0 to +0.0dB
OUTPUT LEVELS Refer to page 6-28
CUSTOM Refer to page 6-28
