CONFIGURING ADVANCE INPUT SETTINGS (continued)
ANALOG BYPASS ON, OFF
When set to ON, the RV-5 passes the analog input signal to the Main
Zone audio output connectors. For stereo analog sources, the input is
sent to the FRONT L/R outputs. For a 5.1-channel analog source, the
(L) input is sent to the FRONT L output. The (R) input is sent to the
FRONT R output. The (C) input is sent to the center output. The
(SUB) input is sent to the SUB output. The (LS) input is sent to the
SIDE L and REAR L outputs. The (RS) input is sent to the SIDE R and
REAR R outputs. When ANALOG BYPASS is set to OFF, the unit routes
the analog input signal through A/D conversion. This makes it
possible to utilize internal processing, including listening modes,
crossovers and equalization. Neither Zone 2 nor Zone 3 provide
multichannel outputs. If the 5.1-channel analog input is selected for
Zone 2 or Zone 3, only the front left and right (L)/(R) inputs will be
available.
When LIVE! is the selected analog input, the MAIN ADVANCED
INPUT SELECT parameter is forced to ANALOG, and ANALOG
BYPASS is disabled.
Note:
If the Main Zone source is 5.1 analog, only the Front L/R channels will be
sent to the Zone 2 S/PDIF outputs.
S-VIDEO 16:9 AUTO, OFF
Controls the passage of anamorphic trigger signals present in some
video sources. When set to AUTO, the RV-5 allows anamorphic video
input signals to pass through the S-Video switcher, enabling
compatible display devices to automatically switch between
anamorphic and non-anamorphic display modes.
When OFF, the RV-5 prevents anamorphic video input signals from
passing through the S-Video switcher, preventing compatible
display devices from automatically switching between anamorphic
and non-anamorphic display modes.
INPUTSSETUP DVD1 MAIN ADVANCED ANALOG BYPASS
INPUTSSETUP DVD1 MAIN ADVANCED S-VIDEO 16:9
